FR-LSH-Fireguard-Cybele

Building Cables

FR-LSH-LEAD FREE
– Flame Retardant Low Smoke & Halogen

Lead-free PVC Insulated Single Core Unsheathed Flexible CABLES, compliant with voltage grades up to 1100 VOLTS IS 694:2010, are known for their reliability and safety. When it comes to ensuring the utmost quality and performance in your electrical installations, trust Qflx, the Best FRLS Cables in Chennai.

Application

Suitable for wiring in conduit and for fixed, protected installation. Particularly suitable for wiring in fire and explosion prone areas , chemical factories, densely wired areas, public building, schools, hospitals, commercial complex, theatres etc.

Technical Data

Approvals: IS 694 marked, FIA/TAC
Voltage Grade: Up to and Including 1100V
Conductor: Bright annealed bare electrolytic grade Copper conductor as per IS 8130:2013
Insulation: Specially formulated Flame retardant Low Smoke and Halogen Lead Free (FR-LSH LF) PVC Compound manufactured In-House by a team of technical experts conforming to IS 5831 which restricts the spread of fire and offers Low Smoke and Low gas evolution which ensures improved visibility for trapped victims and facilitates fire fighting operation

Insulation Conformity:

IS 5831, Type A/Type D - FR-LSH LF

Colours Marking Packing: ● Red ● Black ● Green ● Yellow ● Blue or any other colour as per customer requirement.
Marking: The cables are printed with marking of Q-FLX CABLES 1100V SQMM FR-LSH LF IS 694 ISI CM/L 1115123
Packing: The cables are packed as 90m coil in protective cartons from 1 sq.mm up to 6 sq.mm.. Longer length available up on request.

Product Features

101 % Copper Conductivity, (IACS)	Extra Annealing
100% Bunched Copper	100% Lead Free
Self Extinguishing	High Temp Index
Higher Oxygen Index	Low Smoke Density
Low Halogen Acid Gas Evolution	-

Flame Retardant Low Smoke and Halogen Properties (FR – LSH - LF)

TEST	FUNCTION	SPECIFICATION	VALUE
Critical Oxygen Index	To determine the percentage of oxygen required for combustion of insulating material at room temperature	IS 10810 (Part 58): 1998	Oxygen Index shall not be less than 29%
Temperature Index	To determine at what temperature normal oxygen content of 21% in air will support combustion of insulating material	IS 10810 (Part 64): 2003	Temperature Index should be minimum 250^°C at 21% of Oxygen
Halogen Acid Gas Evolution	To ascertain the amount of Hydrochloric acid gas evolved from insulation of wire under fire	IS 10810 (Part 59): 1988	The gas evolved shall not exceed 20% by weight
Smoke Density	To determine the amount of Smoke emitted	IS 13360 (Part 6/Sec 9)2001	Smoke Density Rating Max.60%

***Also meets the requirement of Flammability Test as per IS 694:2010

Technical Specification of Single Core, FR-LSH PVC Insulated Unsheathed Cable 1100V

Nominal Area of Conductor	Number and Nominal Diameter of Wire	Nominal Thickness of insulation	Maximum Overall Diameter	Current Rating (Amps)		Maximum DC Conductor Resistance at 20°C
mm2	No./mm	mm	mm	Casing	Concealed	Ohm(fl)/km
1	14 /03*	0.7	3.2	14	13	18.1
1.5	22 /03*	0.7	3.3	18	16	12.1
2.5	36 /03*	0.8	4.0	24	20	7.41
4	56 /03	0.8	4.8	30	26	4.95
6	84 /03**	0.8	5.3	38	33	3.30

***As per Class 2 Conductors of IS 8130:2013** As per Class 5 Conductors of IS 8130:2013 Conforms to IS 694: 2010.

Note: The number and Diameter of the conductor strands are for reference only. The size of the conductor is determined by its resistance. it may vary within the limits of related Classes and tables of IS 8130:2013.
The values given above are subject to tolerances as per relevent standards.
Sample Card available on request 1.0 to 4.0 Sqmm
